The rest of the stack is populated by dual PCIe x1 slots via the Gen2 controller in the Z97 chipset, plus dual PCI slots that connect through a PCIe bridge chip. Nvidia’s SLI endorsement only applies to two-card rigs. Three-way setups are only supported for CrossFire, though. The lanes are split in x16/x0/x0, x8/x8/x0, or x8/x4/x4 configs depending on the number of cards installed. Dual-double-wide setups leave one slot’s worth of space between the cards, which should help airflow to the GPU cooler on the first one.Īll three x16 slots get their Gen3 connectivity from the CPU. The board can accept three double-wide cards or dual triple-wide beasts. We can’t test compatibility with every combination of cooler and memory, but we’ve have detailed socket clearance measurements later in the review.Ĭlearances are sometimes a factor for multi-card graphics configurations, but not on the UD5H. Like other Haswell boards, the Z97X-UD5H puts the DIMM slots right next to the socket. Graphics cards installed in the top PCIe x16 slot shouldn’t interfere with larger CPU coolers, either, but taller memory modules might get in the way. The VRM heatsinks should be short enough to avoid bumping into larger aftermarket coolers. Cooler installation can be more difficult as a result, especially if the retention bracket relies on thumbscrews. The UD5H’s billboard-like chipset heatsink at least stays out of the way, but the VRM heatsinks crowd the area around the CPU cooler retention holes.
Gigabyte freely admits that its oversized heatsinks are more about marketing than cooling. The Z97X-UD5H -BK also commands a stiff premium it’s selling for $45 more than the standard version right now. However, it undergoes a week-long stress test before leaving the factory, and it’s covered by a five-year warranty instead of the usual three-year deal. Apart from the tinting, this Black Edition variant is physically identical to the standard UD5H. If you prefer something a little more understated, the Z97X-UD5H has an evil twin with black heatsinks and only a hint of gold trim. The gold is a little gaudy for my tastes, but it doesn’t look too bad when combined with the matte board and largely blacked-out components. Yep, Gigabyte is doing the bling-on-black thing for its Ultra Durable boards this year. But how do those features pan out in the real world, and what’s it like to actually use the board? We spent a couple of weeks with the UD5H to find out, and we learned a few interesting things along the way. At $189.99 online, it’s not too expensive, either.Ĭompetitively-priced, feature-packed boards are kind of Gigabyte’s thing.
Gigabyte motherboard utilities serial#
This upper-mid-range offering hangs a trio of PCIe x16 slots off the CPU, boasts a full complement of next-gen storage interfaces, and includes extra Ethernet, Serial ATA, and USB connectivity.
Gigabyte motherboard utilities series#
The Ultra Durable series follows a more traditional mold for enthusiast-focused motherboards, and the Z97X-UD5H is a particularly loaded example. And then there’s the classic Ultra Durable family, which is perfectly suitable for gaming and loaded with plenty of options for more conventional overclockers.
The overclocking-oriented models are optimized for competitive benchmarking and sub-zero cooling. The gaming-specific boards have tweaked peripheral payloads designed to appeal to gamers. Gigabyte’s Z97 lineup is split between three main factions.
